Oil Water Temperature Sensor 1/8 NPT Electric Gauge 0~150℃

• Premium brass construction, strong and durable
• Easy to install with quick assembly
• Temperature range: 0-150°C / 0-300°F
• 1/8 NPT male threads
• Universal fit for most vehicles

Condition: 100% Brand new
Material: Brass
Color: Gold
Fitment: Universal
Thread: 1/8 NPT external thread
Temperature Range: 0~150°C (0-300°F)
Package List: 1 * Electrical Temperature Sender

Features: Direct replacement for faulty or damaged aftermarket oil/water temperature gauge sensors. Universal 1/8″ NPT oil/water temp sensor with a temperature range of 0-150°C / 0-300°F. This is a single-wire sensor; the signal is sent to the gauge, and the sensor is grounded through the thread when installed into the engine or sandwich plate. The brass outer case serves as the ground. Single connection sensor with temperature reading range of 0-150°C. 1/8 NPT male threads. Range: 0~150°C (0-300°F). Universal fit on all imported and domestic cars.

Temperature to Resistance:
37.8°C — 450 ±45 Ohm
104.4°C — 46.6 ±2.3 Ohm
100°F — 450.0 ±45.0 Ohm
150°F — 158.20 ±15.82 Ohm
200°F — 64.30 ±6.43 Ohm
250°F — 29.25 ±2.93 Ohm
300°F — 14.96 ±2.25 Ohm
